Engine compatability
Torque Converter is compatible on most small engines with horizontal shaft.
Briggs/Robin/Tecumseh/Honda (and clones)/Kohler/Clinton/Lifan
Maximum Torque
This kart torque converter ensures maximum torque and will help you get more power from a small engine by reducing engine load.
Driven Clutch
This kart torque
converter has a 1″ drive clutch with a 1/4″ keyway and a 7/8″ driven
clutch with a 3/16″ keyway. It is suitable for 8-16HP mid-range torque
converter systems.
,
Other Accessories
40 Series Torque Converter Kit Includes: 1x 1″ Driver Clutch
1x 7/8″ Driven Clutch. Fits all engines with a 1″ straight crankshaft with 1/4″ keyway. DRIVEN CLUTCH HAS A 3/4″ BORE,Replaces Comet ,Also Fits Manco Go Karts. Replaces Comet 40 Series Driver and Driven is Very reliable units. Normally used on 8hp to 16hp engines. Driver- 1″ bore with 1/4″ key way. Uses 7/8″ wide belt. Driven- 3/4″ bore with 3/16″ key way.
OEM Parts
The shaft diameter of
the driven clutch is 3/4 “. It replaces the comets 209133A, 209133,
209139A, 209139, 209151A, 209151, 2432, 203015A, 203015, etc. It is also
suitable for Manco Go-karts and replaces Manco 2432.
Widely Applicable
This torque converter
go-kart can be widely used in CVT gearboxes for karts, scooters, small
vehicles, small, light aircraft, golf karts, odyssey, snowmobiles, ATVs,
lawn equipment, industrial, winches, etc. system.
,
40 Series Go Kart Torque Converter Driven
Specifications
Material: Iron
Driver clutch bore: 1″ (25.4mm)
Driven clutch bore: 3/4″ (19.05mm)
Engagement range: 1600 – 3300 RPM
Recommended engine: 8HP – 16HP, 1″shaft with 1/4″ flat keyway
Package Content
1 X 1″ Driver Clutch
1 X 3/4” Driven Clutch
40 Series Go Kart Torque Converter Driven
Asymmetric torque converter design has been very popular the past 30 years.
This clutch will help you get more power out of your small engine by reducing engine load.
A torque converter acts similar to a transmission, allows higher speeds out of your small engine, and smoother acceleration.
Quality Material
Important Parameters
Complete Accessories
Unit Replaces
High Adaptability
