Steel Solid Axles, Short Stepped EndOur premium Deluxe axles are made of a higher
strength steel. The ends step down from 1″ to 3/4″ and
have a 3/4-16″ thread. Two 1/4″ keyways are offset 180″
for stress relief, balance and unrestricted positioning of
brakes, bearings and hubs. Ends are drilled for your cotter
pins or safety wire. Plated and poly-wrapped for protection.
Brightly Plated Deluxe Steel
180″ Offset Keyways
1″ & 1-3/4″ Axle Diameters
1-1/2″ Stepped-Down Threaded Ends
1-1/8″ Thread Length
AXLE
OD
OVERALL
LENGTH
SHOULDER TO
SHOULDER
PART
NO.
1″
36″
33″
1412-36
1″
38″
35″
1412-38
1-3/4″
40″
37″
1412-40
