This timing chain guide set is the replacement part for the HiSun 500cc UTV.
Product Details:
Upper and Lower Plate
White arm is 279mm [10.98″] long
White arm is 13mm [.51″] wide
Black arm is 253mm [9.95″] long not including metal bracket
Black arm is 20mm [.78″] wide at widest point
Metal bracket on black arm has two 6.3mm holes
14630-004-0000
14520-004-0000
Fits many makes and models including 500cc ATV’s and UTV’s made by Bennche, Big Muddy, Hisun, Massimo, Menards Yardsport, Supermach and Q Link.
Product detail
Timing Chain Guide & Tensioner Plate Set – Hisun 500cc
